제품 상세 정보:
|
| 모델 번호: | C050VVN01.5 | 브랜드: | AUO |
|---|---|---|---|
| 사이즈: | 5inch | 결의안: | 800×480 RGB |
| 밝기: | 500 cd/m2 | 온도 범위: | 저장 임시. 다음 -40 ~ 95 'Ｃ 작동 온도. 다음 -30 ~ 85 'Ｃ |
| 램프 유형: | WLED | 신호 인터페이스: | LVDS |
| 하이 라이트: | WLED LVDS AUO LCD 디스플레이,CCFL LVDS AUO TFT LCD |
||
| Basic Information : | Brand Name | Model Name | Type | Model Alias |
|---|---|---|---|---|
 |
C050VVN01.5 | a-Si TFT-LCD , LCM | - | |
| Maximum Ratings : | RoHS | Operating Temperature | Storage Temperature | Vibration Level |
|
-30 ~ 85 °C | -40 ~ 95 °C | - |
| Screen Size : | 5.0" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 800(RGB)×480, WVGA | RGB Vertical Stripe | 0.04525×0.13575 mm | 0.13575×0.13575 mm [187PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 108.6×65.16 mm | - | - | - | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 15:9 | Landscape type | ||
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| - | AMVA, Normally Black, Transmissive | 1000:1 (Min.) (Transmissive) | |
| Good View at | Viewing Angle | Response Time | |
| Symmetry | 80/80/80/80 (Typ.)(CR≥10) |
15/30 (Max.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| - | 16.2M (6-bit + FRC) | - |
| Refresh Rate : | 60Hz C050VVN01.5 supports display 800(RGB)×480 (WVGA) with aspect ratio of 15:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 108.6(W)×65.16(H) mm. As a AMVA, Normally Black, Transmissive LCM product, C050VVN01.5 can provides 1000:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 15/30 (Max.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + FRC gray scale signal for each dot, thus presenting a palette of 16.2M colors. This product adopted WLED as it's backlight systerm which was placed as Edge light type. It's typical vertical frame rate (Fv) is 60Hz. For more latest product detail of C050VVN01.5 we strongly recommend that you should refer to datasheet listed on Panelook.com or contact with AUO.
