제품 상세 정보:
|
| 모델명: | LM5Q321 | 제조사: | 전문가 |
|---|---|---|---|
| 활동 분야 (mm): | 100.8 × 75.6 (H×V) | 화면 크기: | 5.0 인치 |
| 배열: | RGB 세로줄 | 백라이트: | 1 PC CCFL |
| 화소 갯수: | 320(RGB)×240 (QVGA) 80PPI | 맥스. 평가: | 저장 임시. 다음 -25 ~ 60 'Ｃ 작동 온도. 다음 0 ~ 50 'Ｃ |
| 하이 라이트: | ＳＶＧＡ 감도가 좋은 TFT LCD 스크린,XGA 산업적 엘시디 판넬,LVDS TFT LCD 디스플레이 |
||
LM5 Series LM5Q321 LM5Q321R
| Basic Detail : | Manufacturer | SHARP | Model Name | LM5Q321 |
|---|---|---|---|---|
| Panel Type | CSTN-LCD , LCM | Another Name | - | |
| Panel Size | 5.0 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | 0 ~ 50 °C | ST Temperature | -25 ~ 60 °C |
| Basic Information : | Luminance | - | Contrast Ratio | - |
|---|---|---|---|---|
| Good View at | - | Response Speed | - | |
| Viewing Angle | - | Operating Mode | STN, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | - | Support Color | Color |
| Pixel Features : | Number of Pixel | 320(RGB)×240 [QVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.105×0.315 mm | Pixel Pitch(W×H) | 0.315×0.315 mm [80PPI] | |
| Physical Size : | Active Viewing | 100.8(W)×75.6(H) mm | Overall Dim. | - |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 4:3 | Shape Style |
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
