제품 상세 정보:
|
| 모델명: | LK695D3LA58 | 화면 크기: | 70 인치 |
|---|---|---|---|
| 광도: | 700 cd/m ² (Typ.) | 화면 형태: | LCM, Si TFT-LCD |
| 화소 갯수: | 1920년 (고정 헤드 디스크) 31PPI | 백라이트: | LED 드라이버로, 50K 시간인 WLED |
| 시그널 타입: | LVDS (2 ch, 8비트), 연결기 92 핀 | 맥스. 평가: | 저장 임시. 다음 -25 ~ 60 'Ｃ 작동 온도. 다음 0 ~ 50 'Ｃ |
| 하이 라이트: | WLED 높은 광도 LCD 디스플레이,CCFL TFT LCD 스크린,ＳＶＧＡ 날카로운 TFT LCD 디스플레이 |
||
| Pixel Features : | Pixel Format | 1920(RGB)×1080 [FHD] | Dot Pitch | 0.2672×0.8015 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.8015×0.8015 mm (H×V) [31PPI] | |
| Mechanical Size : | Display Area | 1538.88×865.62 mm (H×V) | Bezel Area | 1544.0×876.8 mm (H×V) |
| Outline Dim. | 1566×901.8 mm (H×V) | Outline Depth | 21.8/31.6 (Typ./Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape / Portrait |
| Aspect Ratio | 16:9 (H:V) | Shape Style | ||
| Other Features : | Weight | 26.0±1.5Kgs | Surface | Antiglare, Hard coating (2H) |
| Basic Information : | Brightness | 700 cd/m² (Typ.) | Contrast Ratio | 5000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) | Optical Mode | ASV, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 8 (Typ.)(G to G) (ms) | |
| Color Performance : | Chromaticity | Wx:0.318; Wy:0.335 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 6187K | White Uniformity | 1.33 (Max.)(5 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 76% | sRGB | 95% coverage |
| Adobe RGB | 74% coverage | DCI-P3 | 79% coverage | |
| Rec.2020 | 57% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmittance | - |
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | 50K(Typ.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Edge light type | |
| Interface Features : | Type | Connector | Position | - | Lamp Driver | With LED Driver |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| YEONHO | 20022WR-14B1 | 2.0 mm | 14 pins | 1 pcs | ||
| Driver Electrical : | Voltage Input | 24.0±2.4V | Current Input | 7.8/8.6A (Typ./Max.) | ||
| Signal Systerm : | LVDS (2 ch, 8-bit) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 12.0V (Typ.) | Current Input | 0.75/2.0A (Typ./Max.) | ||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JAE | FI-RNE51SZ-HF-R1500 | 0.5 mm | 51 pins | 1 pcs | ||
| JAE | FI-RNE41SZ-HF-R1500 | 0.5 mm | 41 pins | 1 pcs | ||
LK695 Series LK695D3LA58 LK695D3LA18
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
