제품 상세 정보:
|
| 브랜드: | 전문가 | 모델: | LQ055W1GC01 |
|---|---|---|---|
| 대각선 사이즈: | 5.5 인치 | 픽셀 포맷: | 1024×600RGB |
| 윤곽: | RGB 세로줄 | 타입: | Si TFT-LCD, LCM |
| 광도: | 200 cd/m ² (Typ.) | 조명 공급원: | W/O 드라이버인 WLED [8S1P] |
| 환경: | 작동 온도 : 0 ~ 60 'Ｃ ; 저장 온도 : -20 ~ 70 'Ｃ | 인터페이스 타입: | 소형 LVDS 40 핀 FPC |
| 하이 라이트: | WLED 높은 광도 LCD 디스플레이,CCFL TFT LCD 스크린,ＳＶＧＡ 날카로운 TFT LCD 디스플레이 |
||
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| 200 cd/m² (Typ.) | TN, Normally White, Transmissive | 300:1 (Typ.) (Transmissive) | |
| Good View at | Viewing Angle | Response Time | |
| 9 o'clock | 60/50/70/70 (Typ.)(CR≥10) | 25 (Typ.)(Tr+Td) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| 6485K | 262K (6-bit) | X:0.313; Y:0.329 |
| Screen Size : | 5.5" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 1024(RGB)×600, WSVGA | RGB Vertical Stripe | 0.039×0.117 mm | 0.117×0.117 mm [217PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 119.808×70.2 mm | - | 130.2×81.15 mm | 1.95/2.15 (Typ./Max.) mm | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 17:10 | Landscape type | ||
| Other Spec : | Mass | Panel Cover | Surface Treatment | |
| 32.0/36.0g (Typ./Max.) | - | Clear, Hard coating (2H) | ||
| Signal Electrical : | Input Voltage | Input Current | Power Consumption | |||
|---|---|---|---|---|---|---|
| 2.5/7.9V (Typ.)(VCC/VDD) | 9.0/14.0mA (Typ.)(ICC/IDD) | - | ||||
| Interface Features : | Signal Type | Physical Type | Interface Position | |||
| Mini LVDS | FPC | - | ||||
| Interface Detail : | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| 1 pcs | 40 pins | 0.5 mm | ||||
| Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | - | 8S1P | 1 string | - (NSSW206A (NICHIA)) | |
| WLED Electrical : | Input Voltage | Input Current | Power Consumption | |||
| 21.6/22.7V (Typ.)(100cd/200cd) | 6.0/12.0mA (Typ.)(100cd/200cd) | 130/273mW (Typ.)(100cd/200cd) | ||||
| Interface Features : | WLED Driver State | Physical Type | Interface Position | |||
| No | Included in panel signal interface | - | ||||
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
